iCMS.pollerd
Class GenericData

java.lang.Object
  MyEventManager
      iCMS.pollerd.GenericData

All Implemented Interfaces:

MonitoredItem

Direct Known Subclasses:

ApplicationData, CmsData, LocationData, NodeData, NodeGroupData, NodeTypeData, ProbeData

public class GenericData
extends MyEventManager
implements MonitoredItem

This class is a data holder for general data

Revision Changes :

• 1.0.0 - initial version
• 2.0.0 - Release for GPL as iCMS
• 2.0.1 - Added Parent Code for Advanced SNMP Manager
• 2.0.2 - Probes can now be blocked from propagation
• 2.0.3 - There will be only on AdvancedSNMPManager is the system
• 2.0.4 - When having Children and Probes, the latter will be blocked if unknown

Version:

2.0.4

Author:

Chris Lukassen

Field Summary

protected String	allocatedMibs
protected boolean	canStart
protected boolean	canStop
protected Hashtable	children
protected Vector	descr
protected String	host
protected Vector	info
protected Vector	mibDirs
protected Vector	mibs
protected String	name
protected GenericData	parent
protected ProbeData	probe
protected boolean	propagate
protected AdvancedSnmpManager	snmpMan
protected int	status
protected String	token
protected String	type

Constructor Summary

GenericData(GenericData parent)
default constructor

Method Summary

void	addChild(GenericData child) add a child to this item
void	addDescription(String descr) adds a descriptive line for this items description
void	addMib(String mib) adds a mib to this item
void	addMibDir(String mibDir) adds a mibdir to this item
protected void	allocateAndAddMib(String newMib) sets this item's allocated mibs and forward it to it's childeren it takes in account allocatedMibs (eg /usr/lib/mibs) and expands it with its newMib when found in a dir (setMibDir)
boolean	canStart() can this item be started ?
boolean	canStop() can this item be stopped ?
Object	clone(GenericData parent) create an exact copy of this item, with all settings included
GenericData	getChild(String name) get a child from this item
Hashtable	getChildren() get this item's children
Vector	getDescription() get this item's description as lines of Strings
String	getHost() get this item's host name
Vector	getMibDirs() gets the mib dirs of this item
String	getMibDirsAsString() gets the mib dirs of this item as a string
Vector	getMibs() gets the mibs of this item
String	getName() get this item's name
ProbeData	getProbe() returns this items probe, if available
boolean	getPropagate() get this item's propagate status
int	getStatus() get this item's status
String	getType() get this item's type (handy when overloaded) returns "generic" for this class but other names for subclasses
void	initMonitoring(AdvancedSnmpManager snmpMan) initializes the monitoring process it is wise to call setMibDirs, setMib and setAllocatedMibs before calling init, as from here they propagate down to the children
void	list(PrintStream out, boolean stat, String root) list out the all info of this item and its children including stat if stat is true
void	myEventOccurred(MyEvent evt) Event Handling
void	print(PrintStream out, boolean all, String root) print out the all info of this item
void	removeAllChildren() remove all of this items children
Object	removeChild(String name) remove one of this items children
void	setAllocatedMibs(String alreadyAllocatedMibs) sets this item's allocated mibs and forward it to it's childeren it takes in account alreadyAllocatedMibs (eg /usr/lib/mibs) and expands it with its mibs (addMib, setMibs) when found in a dir (setMibDir)
void	setChildren(Hashtable children) set all of this items children
void	setDescription(Vector descr) sets all descriptive lines of Strings for this item
void	setHost(String host) sets this item's host name
void	setInfo(Vector info) sets all informational items for this item
void	setItemToken(String name) sets this item's token e.g /x/y/z
void	setMibDirs(Vector dirs) sets this item's mibdirs
void	setMibs(Vector mibs) sets the mibs of this item
void	setName(String name) sets the name of this item
void	setParent(GenericData parent) sets the parent of this item
void	setProbe(ProbeData newProbe) sets the probe for this item
void	setPropagate(boolean prop) sets this item's propagation property.
void	setPropagate(String prop) sets this item's propagation property.
void	setStatus(int status) sets this item's status
int	start() start item
void	startMonitoring() starts the monitoring process
int	stop() stop item

Methods inherited from class java.lang.Object

clone, equals, finalize, getClass, hashCode, notify, notifyAll, toString, wait, wait, wait

Methods inherited from interface iCMS.pollerd.MonitoredItem

addMyEventListener, removeMyEventListener

Field Detail

children

protected Hashtable children

name

protected String name

token

protected String token

host

protected String host

type

protected String type

propagate

protected boolean propagate

status

protected int status

probe

protected ProbeData probe

mibs

protected Vector mibs

allocatedMibs

protected String allocatedMibs

mibDirs

protected Vector mibDirs

info

protected Vector info

descr

protected Vector descr

canStop

protected boolean canStop

canStart

protected boolean canStart

parent

protected GenericData parent

snmpMan

protected AdvancedSnmpManager snmpMan

Constructor Detail

GenericData

public GenericData(GenericData parent)

default constructor

Method Detail

setMibs

public void setMibs(Vector mibs)

sets the mibs of this item

setParent

public void setParent(GenericData parent)

sets the parent of this item

setName

public void setName(String name)

sets the name of this item

setInfo

public void setInfo(Vector info)

sets all informational items for this item

setDescription

public void setDescription(Vector descr)

sets all descriptive lines of Strings for this item

Specified by:

setDescription in interface MonitoredItem

addMib

public void addMib(String mib)

adds a mib to this item

addMibDir

public void addMibDir(String mibDir)

adds a mibdir to this item

addDescription

public void addDescription(String descr)

adds a descriptive line for this items description

Specified by:

addDescription in interface MonitoredItem

setItemToken

public void setItemToken(String name)

sets this item's token e.g /x/y/z

Specified by:

setItemToken in interface MonitoredItem

setAllocatedMibs

public void setAllocatedMibs(String alreadyAllocatedMibs)

sets this item's allocated mibs and forward it to it's childeren it takes in account alreadyAllocatedMibs (eg /usr/lib/mibs) and expands it with its mibs (addMib, setMibs) when found in a dir (setMibDir)

allocateAndAddMib

protected void allocateAndAddMib(String newMib)

sets this item's allocated mibs and forward it to it's childeren it takes in account allocatedMibs (eg /usr/lib/mibs) and expands it with its newMib when found in a dir (setMibDir)

setMibDirs

public void setMibDirs(Vector dirs)

sets this item's mibdirs

setPropagate

public void setPropagate(boolean prop)

sets this item's propagation property. If set to false, it's parent will ignore it's status

setPropagate

public void setPropagate(String prop)

sets this item's propagation property. If set to false, it's parent will ignore it's status
Upper or lower case spelling of "TRUE" sets it to true, else false

setHost

public void setHost(String host)

sets this item's host name

setStatus

public void setStatus(int status)

sets this item's status

setProbe

public void setProbe(ProbeData newProbe)

sets the probe for this item

addChild

public void addChild(GenericData child)

add a child to this item

getMibDirsAsString

public String getMibDirsAsString()

gets the mib dirs of this item as a string

getMibDirs

public Vector getMibDirs()

gets the mib dirs of this item

getMibs

public Vector getMibs()

gets the mibs of this item

getChild

public GenericData getChild(String name)

get a child from this item

getPropagate

public boolean getPropagate()

get this item's propagate status

getChildren

public Hashtable getChildren()

get this item's children

stop

public int stop()

stop item

start

public int start()

start item

canStart

public boolean canStart()

can this item be started ?

canStop

public boolean canStop()

can this item be stopped ?

getHost

public String getHost()

get this item's host name

getStatus

public int getStatus()

get this item's status

Specified by:

getStatus in interface MonitoredItem

getType

public String getType()

get this item's type (handy when overloaded) returns "generic" for this class but other names for subclasses

getName

public String getName()

get this item's name

Specified by:

getName in interface MonitoredItem

getDescription

public Vector getDescription()

get this item's description as lines of Strings

Specified by:

getDescription in interface MonitoredItem

setChildren

public void setChildren(Hashtable children)

set all of this items children

removeAllChildren

public void removeAllChildren()

remove all of this items children

removeChild

public Object removeChild(String name)

remove one of this items children

startMonitoring

public void startMonitoring()

starts the monitoring process

Specified by:

startMonitoring in interface MonitoredItem

clone

public Object clone(GenericData parent)

create an exact copy of this item, with all settings included

initMonitoring

public void initMonitoring(AdvancedSnmpManager snmpMan)

initializes the monitoring process

it is wise to call setMibDirs, setMib and setAllocatedMibs before calling init, as from here they propagate down to the children

Specified by:

initMonitoring in interface MonitoredItem

getProbe

public ProbeData getProbe()

returns this items probe, if available

Specified by:

getProbe in interface MonitoredItem

print

public void print(PrintStream out,
                  boolean all,
                  String root)

print out the all info of this item

list

public void list(PrintStream out,
                 boolean stat,
                 String root)

list out the all info of this item and its children including stat if stat is true

myEventOccurred

public void myEventOccurred(MyEvent evt)

Event Handling
