luky.snmp
Class AdvancedSnmpManager

java.lang.Object
  luky.events.MyEventManager
      luky.snmp.AdvancedSnmpManager

All Implemented Interfaces:

Runnable, Observer

public class AdvancedSnmpManager
extends MyEventManager
implements Runnable, Observer

The AdvancedSnmpManager creates a re-entrend version of the SnmpManager the idea is to save significant memory and boost performance.

The fired ExtendedEvents hold event data "host" "oid" and "result"

Revision Changes :

• ver 1.00 initial release
• ver 1.01 add oid returns the resolved oid, which should match the event
• ver 1.02 a timeout no longer results in a crash
• ver 2.00 create facility for multi hosts
• ver 2.01 bug fix to return proper oid on good reception
• ver 2.02 allow result to be not, decoded

Version:

2.02

Author:

Chris Lukassen

Field Summary

Fields inherited from class luky.events.MyEventManager

listenerList

Constructor Summary

AdvancedSnmpManager(String community, int port, int interval)
Constructor.

Method Summary

String	addOid(String host, String oidName, String mib) adds a new Oid for this manager
boolean	initOk() tells if the constructor could initialize the snmp context correctly better not use the manager is it is false
String	performGet(String host, String oidName, String mib) performs a snmp get for oidName (optionally in mib) with value decodes the result
String	performGet(String host, String oidName, String mib, boolean decode) performs a snmp get for oidName (optionally in mib) with value
String	performSet(String host, String oidName, String mib, String value) performs a snmp set for oidName (optionally in mib) with value
void	run() performs a get operation for the added oid, in a continious polling
void	start() starts a new thread to poll stored oid, sends event on state change
void	stop() stop the polling, destoys the context of the poll
void	update(Observable obs, Object ov) Implementing the Observer interface.

Methods inherited from class luky.events.MyEventManager

addMyEventListener, fireMyEvent, removeMyEventListener

Methods inherited from class java.lang.Object

clone, equals, finalize, getClass, hashCode, notify, notifyAll, toString, wait, wait, wait

Constructor Detail

AdvancedSnmpManager

public AdvancedSnmpManager(String community,
                           int port,
                           int interval)

Constructor.

Parameters:

community - snmp community string (suggest: "public")

port - snmp port, 161 is normal

interval - delay between polls, in microseconds

Method Detail

addOid

public String addOid(String host,
                     String oidName,
                     String mib)

adds a new Oid for this manager

Parameters:

host - the host to be polled

oidName - can be a number .1.3.etc or a id eg. sysUptime.0

mib - mib file (full path) to translate a mib, if the oid needs it e.g. sysUptime.0

Returns:

the resolved oid

update

public void update(Observable obs,
                   Object ov)

Implementing the Observer interface. Receiving the response from the AdvancedSnmpManagerObject. Fires events to the listners

Specified by:

update in interface Observer

Parameters:

obs - the AdvancedSnmpManagerObject variable

ov - the varbind

See Also:

varbind

performSet

public String performSet(String host,
                         String oidName,
                         String mib,
                         String value)

performs a snmp set for oidName (optionally in mib) with value

Parameters:

oidName - can be a number .1.3.etc or a id eg. sysUptime.0

mib - mib file (full path) to translate a mib, if the oid needs it e.g. sysUptime.0

Returns:

decoded result

performGet

public String performGet(String host,
                         String oidName,
                         String mib)

performs a snmp get for oidName (optionally in mib) with value decodes the result

Parameters:

oidName - can be a number .1.3.etc or a id eg. sysUptime.0

mib - mib file (full path) to translate a mib, if the oid needs it e.g. sysUptime.0

Returns:

decoded result

performGet

public String performGet(String host,
                         String oidName,
                         String mib,
                         boolean decode)

performs a snmp get for oidName (optionally in mib) with value

Parameters:

oidName - can be a number .1.3.etc or a id eg. sysUptime.0

mib - mib file (full path) to translate a mib, if the oid needs it e.g. sysUptime.0

decode - boolean, specifing if the result should be decoded

Returns:

result

run

public void run()

performs a get operation for the added oid, in a continious polling

Specified by:

run in interface Runnable

initOk

public boolean initOk()

tells if the constructor could initialize the snmp context correctly better not use the manager is it is false

Returns:

the status in Constants format

start

public void start()

starts a new thread to poll stored oid, sends event on state change

stop

public void stop()

stop the polling, destoys the context of the poll
